Tiger Valve — Industrial Valves, Wellhead Equipment & Actuators

• Trunnion Mounted Ball Valves — API 6D Pipeline & High-Pressure Service
• Flanged & Threaded Floating Ball Valves — General Process Service
• Shut-Off Pig Valves — Pipeline Pigging & Maintenance
• Gate, Globe & Check Valves — Cast Steel, API 6A
• Wellhead Equipment — Oilfield & Gas Production
• Resilient Seated Butterfly Valves — Water, HVAC & Industrial
• Rack & Pinion and Piston Pneumatic Actuators
• Metal-Seated Ball Valves — High Temperature & Abrasive Service

Tiger Valve Company is a manufacturer and supplier of high-quality industrial valves, wellhead equipment, and pneumatic actuators serving the oil and gas, petrochemical, chemical, power generation, water, and general process industries. Tiger Valve offers an extensive product portfolio covering the full range of valve types and pressure classes — from standard ANSI flanged ball valves and butterfly valves to API 6A wellhead chokes, trunnion mounted pipeline ball valves, and specialty pig valves — all supported by comprehensive engineering and quality documentation packages.

Tiger Valve's products are built to API, ANSI, ASME, and international standards and are available in a broad range of body and trim materials including carbon steel, stainless steel, duplex, super duplex, and high-alloy constructions for corrosive, high-pressure, and high-temperature applications. Tiger Valve's competitive pricing, short lead times, and strong documentation capabilities make them a preferred source for oil and gas, midstream, downstream, and industrial projects.

ATSCO Sales & Service is Tiger Valve's factory-authorized manufacturer's representative for the Rocky Mountain region, providing application engineering, project support, and local inventory for Tiger Valve products across Utah, Idaho, Nevada, and Wyoming. Our in-house machine shop can actuate any Tiger Valve product with pneumatic or electric actuators for complete valve automation packages. Call 801-565-7277 for sizing and application assistance.

Ball Valves — Trunnion, Floating & Metal-Seated

Tiger Valve manufactures a comprehensive range of ball valves for pipeline and process service. Trunnion Mounted Ball Valves per API 6D are designed for large-diameter, high-pressure pipeline isolation and block-and-bleed applications, featuring a fixed-trunnion ball design that reduces operating torque and provides superior seat sealing under high differential pressure. Available in full-bore and reduced-bore configurations from 2 inch through 60 inch and ANSI Class 150 through 2500.

Flanged Floating Ball Valves provide cost-effective shutoff for general process service in sizes from ½ inch through 12 inch and ANSI Class 150 through 900. Metal-Seated Ball Valves are engineered for high-temperature, abrasive, and erosive service conditions where soft seats would fail — including steam, hot oil, catalyst handling, sand-laden fluids, and cryogenic service. Seal Welded Threaded Ball Valves eliminate potential leak paths in instrument and utility piping for demanding oil and gas applications.

Shut-Off Pig Valves

Tiger Valve Shut-Off Pig Valves are purpose-designed for pipeline pigging operations, combining a full-bore ball valve with integrated pig launching and receiving capability. The pig valve eliminates the need for separate barred tees and pig traps in many applications, reducing installation cost and piping complexity. Tiger Valve pig valves are available in sizes from 2 inch through 24 inch, ANSI Class 150 through 900, with carbon steel, stainless steel, and duplex body options to suit sour service, offshore, and chemically aggressive pipeline applications.

Gate, Globe & Check Valves

Tiger Valve's Cast Steel Gate, Globe, and Check Valves cover the standard ANSI process valve requirements for oil and gas, refinery, chemical, and power generation service. Gate valves provide full-bore isolation with minimal pressure drop, globe valves deliver precise throttling and flow control, and swing check valves prevent backflow in pump discharge and process piping. All cast steel valves are available per ASME B16.34 in Class 150 through 2500 with carbon steel (WCB), low-temperature carbon steel (LCB), and stainless steel (CF8M) body options.

API 6A Gate Valves are engineered for wellhead and christmas tree service, meeting the stringent pressure containment, material, and testing requirements of API Specification 6A for surface wellhead equipment in oil and gas production. Threaded Swing Check Valves provide economical backflow prevention for screwed piping systems in utility and instrument applications.

Wellhead Equipment

Tiger Valve supplies Wellhead Equipment for oil and gas production applications including casing heads, tubing heads, christmas trees, and associated choke and gate valves. Tiger Valve's wellhead products meet API 6A requirements and are available in working pressures from 2,000 psi through 20,000 psi with PSL 1 through PSL 4 product specification levels. Material classes cover DD, EE, FF, and HH for standard and sour gas service per NACE MR0175/ISO 15156. Tiger Valve wellhead equipment is used on onshore oil and gas production wells throughout the Rocky Mountain region, Permian Basin, and other North American producing areas.

Resilient Seated Butterfly Valves

Tiger Valve Resilient Seated Butterfly Valves provide economical quarter-turn shutoff for water, HVAC, and general process service. Available in wafer and lug body styles in sizes from 2 inch through 48 inch, Tiger Valve butterfly valves feature ductile iron or carbon steel bodies with a wide selection of disc materials, seat elastomers, and liner materials to suit potable water, seawater, mild chemicals, and general industrial media. Butterfly valves are available bare-stem for manual operation with lever or gear operator, or with ISO 5211 mounting for pneumatic and electric actuator installation.

Pneumatic Actuators

Tiger Valve manufactures Rack & Pinion Pneumatic Actuators for quarter-turn valve automation in double-acting and spring-return configurations. Built to ISO 5211 and NAMUR standards, Tiger Valve rack-and-pinion actuators are compatible with all major valve brands and automation accessories. Torque outputs range from 10 Nm to 3,000+ Nm to cover the full range of butterfly, ball, and plug valve automation requirements.

Diaphragm and Piston Pneumatic Actuators provide precise pneumatic control for globe valves, needle valves, and other linear-travel applications. Diaphragm actuators offer smooth, responsive action ideal for control valve service with positioners, while piston actuators deliver higher thrust outputs for large valves and high-differential-pressure applications. Both types are available in spring-loaded and double-acting configurations with NAMUR-compliant accessories.

Why Specify Tiger Valve?

• Complete valve portfolio: ball, gate, globe, check, butterfly, pig, and wellhead from one source
• API 6D trunnion ball valves and API 6A wellhead equipment for oilfield service
• Metal-seated and sour-service options for aggressive oil and gas applications
• Competitive pricing and short lead times on standard configurations
• Full ANSI, API, ASME, and NACE documentation packages available
• Carbon steel, stainless, duplex, and high-alloy material options
• In-house pneumatic actuators for complete valve automation packages
• Backed by ATSCO's local application engineering and in-house machine shop

ATSCO Sales & Service has over 50 years of experience supplying industrial valves and actuators to customers across the Rocky Mountain oil and gas, mining, water, and process industries. Please submit an RFQ or call us at 801-565-7277 for pricing, lead time, and application support.
